ADC Diagnostix brand mercury blood pressure instruments combine legendary accuracy with unprecedented reliability that virtually eliminates the risk of mercury leakage. ADC's proprietary Safety first system incorporates a 5.00mm unbreakable plastic cartridge, reservoir lock, and the EZ-Tube system. Features and Benefits Rugged die cast aluminum and ABS housing with textured black baked enamel finish. Wall bracket swivels through 110° arc for enhanced visibility. Graduated unbreakable plastic cartridge tube features 5mm inside bore for unrestricted, friction-free mercury flow. White oversized numerals on contrasting black scale combined with high visibility red graduations for easy reading. EZ-Tube system allows safe, simplified maintenance of the cartridge tube or top cap filters. Filter system keeps mercury clean for reliable performance. Locking reservoir secures mercury during storage, transport, or maintenance. Adcuff black nylon cuff with ADC's proprietary Size Guide marking system prevents mis-cuffing. Dip molded latex inflation bladder withstands heavy use. Latex inflation bulb fitted with filter screen end valve reduces dust build-up. Adflow chrome-plated brass air release valve. Complete with vinyl coated wire cuff basket, 8 foot length (when extended) of coiled latex tubing, all mounting hardware, and comprehensive owner's manual.
Technical Specifications Sphyg Type: Wall Merc Gauge: NA Gauge Warranty: Lifetime Sphyg Accuracy: +/-3mmHg @ 50ºF(10ºC) - 104ºF(40ºC) Sphyg Accuracy at extended temperature range: +/-3mmHg or 2% whichever is greater @ <50ºF(10ºC) and >104ºF(40ºC) Storage Temp: -4ºF (-20ºC) - 131ºF(55ºC) Valve Type: ADFLOW Number of Tubes: 2 Tubes Cuff Type: ADCUFF Cuff Size: Adult Cuff Range: 23-40cm Inflation Warranty: 3 Year Cuff Color: Black Zipper Case: NA
Please Inquire
Lifetime warranty on cartridge tube.
