ADC Diagnostix E-Sphyg 2 Sphygmomanometer

ADC Diagnostix E-Sphyg 2 Sphygmomanometer

Brand:   ADC
Condition:   New
The world's first digital mercury sphyg with auto measurement option.
Have a question? Feel free to Ask a question
Please Sign In to Buy     |    $422.54
If you just logged in, please refresh the page


The world's first digital mercury sphyg with auto measurement option. The unique backlit LCD display mimics the appearance of a traditional mercury column, but can be easily read in low light conditions. A second numeric LCD displays pressure, pulse, and a host of other vital information, the e-sphyg 2 features auto/manual settings. In manual mode, blood pressure is measured using the traditional, time-tested auscultatory method. Auto mode can be used with child, adult, and large adult size cuffs to automatically obtain systolic/diastolic pressure and pulse in about 1 minute. Features and Benefits GRAPHIC back lit mercury free LCD that mimics the appearance of a mercury column for easier interpretation. Multi-function alpha-numeric LCD displays air pressure, deflation rate, systolic, diastolic pressure and pulse (auto mode only). Industry first manual mode allows practitioners to use the time-tested auscultatory method with ANY sized cuff. Automatic inflation to pre-set levels simplifies use. ECV (electronic control valve) precisely controls deflation at one of three pre-established rates for (manual mode) optimum results. NICAD rechargeable battery provides about 200 measurements on a single charge. AC adapter. Includes Small Adult, Adult, and Large Adult latex free ADCuffs™ with exclusive Size Guide™ Marking System Latex free TPU coiled tubing for convenience. Available in desktop, wall mount or mobile configurations.

Additional Information

Materials Included AC adapter Small Adult Latex-Free ADCuff Adult Latex-Free ADCuff Large Adult Latex-Free ADCuff Size Guide™ Marking System NICAD rechargeable battery Note: To connect the available thigh cuff with ADC Diagnostix E-Sphyg 2 Sphygmomanometer; the 891F female connector is needed. Available in 1 Each or Quantity of 10.

Tech Specs

Technical Specifications E-sphyg 2 (9002) Operating Principle: Oscillometric method* Indicator: 300 digits column LCD and 10 digits segment LCD Pressure Indicating Range: 0 to 300 mmHg (cuff pressure) Measuring Range: 50 to 250 mmHg (systolic) 40 to 180 mmHg (diastolic) 40 to 160 bpm (pulse rate) Accuracy: +/-3 mmHg (cuff pressure) +/- 5% of reading (pulse rate) Inflation : Automatic inflation Deflation: Electric control valve Exhaust: Automatic exhaust valve Power Supply: 7.0 VDC AC adapter (MODEL 9605+02225-1UOC) or 4.8 VDC rechargeable NiMH battery Power Consumption : 14W (max.) Memory: single measurement result* Operating Environment: +50°F to +104°F, 15 to 90% relative humidity Storage Environment: -4°F to +122°F, 15 to 95% relative humidity Coverage Arm Circumference Adult Size Cuff: 10.28 to 16.1 inches (26.1 to 40.9 cm) Large Adult Size Cuff: 13.5 to 20.04 inches (34.3 to 50.9 cm) Small Adult Size Cuff: 7.48 to 10.71 inches (19.0 to 27.2 cm) Main Unit Weight: Approx. 2.2 lb. [1000 g], without AC adapter or battery Size: 5.4 x 10.6 x 3.8 in [136 x 266 x 96 mm] (W x D x H)

Shipping Information

Please Inquire

Warranty & Returns

2-year warranty
