A6 Portable B/W Ultrasound System
Details
Sonoscape is a high quality, technology company which has specialized in manufacturing and developing ultrasound systems and ultrasound transducers for many years. Supported by numerous innovative technologies, Sonoscape’s introduces A6 as is a reliable and easy-to-use hand-carried, Ultrasound system with premium image quality which is comparable to high-end cart-based B/W ultrasound systems. Features and Benefits Elegant outline design, weighing only 6kg weight and comes with an optional mobile trolley, the A6 creates a comfortable working environment. 12-inch angle adjustable LCD, with two transducer sockets, the A6 minimizes streamlines your working fatigue workflow. With premium B/W ultrasound technologies, abundant software packages and a series of high density probes, the A6 assists you in reaching new heights of various clinical applications. Built in Li-ion Battery with 3 hours of battery life. Compatible with a broad range of transducers, including AVI/JPEG, DICOM. Superior documentation abilities: USB storage, PDF report, AVI/JPEG, DICOM. Compatible with a broad range of transducers, including 180 degree wide-angle endocavity probe.
Additional Information
Sonoscape is a high quality, technology company which has specialized in manufacturing and developing ultrasound systems and ultrasound transducers for many years. Supported by numerous innovative technologies, Sonoscape’s introduces A6 as is a reliable and easy-to-use hand-carried, Ultrasound system with premium image quality which is comparable to high-end cart-based B/W ultrasound systems. Features and Benefits Elegant outline design, weighing only 6kg weight and comes with an optional mobile trolley, the A6 creates a comfortable working environment. 12-inch angle adjustable LCD, with two transducer sockets, the A6 minimizes streamlines your working fatigue workflow. With premium B/W ultrasound technologies, abundant software packages and a series of high density probes, the A6 assists you in reaching new heights of various clinical applications. Built in Li-ion Battery with 3 hours of battery life. Compatible with a broad range of transducers, including AVI/JPEG, DICOM. Superior documentation abilities: USB storage, PDF report, AVI/JPEG, DICOM. Compatible with a broad range of transducers, including 180 degree wide-angle endocavity probe.
Tech Specs
Technical Specifications Dimensions: 340 x 340 x 150 mm Power Supply: 100 - 220VAC, 50Hz/60Hz Peripheral Port: S-Video, VGA, two USB ports, footswitch, LAN, Print Control System Design: HCU with LCD Monitor, Monitor Angle 30 degree adjustable Image Mode: B, B/B, M, B/M, 4B, THI Gray Scale: 256 Display: 12" anti-glare LCD monitor Transducer connector: 2 (Standard) Digital Technology Tissue Harmonic Imaging (THI) Digital Beam-Forming (DBF) M-tuning one-button image optimization Five variable frequency Chroma fucntion Scanning Angle: Up to 180 degree (Depending on Transducers) Scanning Depth: Up to 320 (Depending on Transducers) Imaging Processing Pre-Processing 8-Segment TGC Imaging Processing Dynamic Range Image Enhancement Scanning Angle Power Range Image Rotation at 90 Degree Interval Post-Processing Gray-Map Black/White Reverse Left-Right Reverse Up-Down Reverse Storage Media: 1GB Standard Image-Storage Capacity, USB Drive Zoom: Panaramic Zoom In Real-Time
Shipping Information
Please Inquire
Warranty & Returns
2-Year Warranty
