HANDYREF-K PORTABLE ARK
Details
The HandyRef-K is lightweight and has excellent weight distribution. Its compact design makes it easy to hold, balance, and use. The intelligently designed button layout is also useful in one-handed operation. New full graphic 3.5-inch color LCD is 40% larger than the previous model. The clear screen design and intuitive icons provide high user-friendliness. Measurement data of 50 patients (100 eyes) can be saved in the main body memory. For inexperienced patients like children, the newly added melody function can ease patient’s anxiety and draw attention. Data can be transferred quickly and easily to PC. Two types of fixation target (scenery or children’s) are available. By using the portable stand, the HandyRef-K can be used as a desktop device. The HandyRef-K adopts an excellent new measurement method; "SynchroScan Technology". Measurements start when the alignment starts, and locks in the data when alignment becomes optimal as a measurement value. Accuracy is further enhanced with the pupil zone imaging method, a super luminescent diode (SLD) and highly sensitive CCD. The features of the HandyRef-K allow easy, accurate measurements while maintaining efficiency.
Tech Specs
Main body Auto refractometer Measurement range Sphere -20.00 to +20.00 D (VD = 12mm) (0.12 / 0.25 D increments) Cylinder 0 to 12.00 D (0.12 / 0.25 D increments) Axis 0 to 180° (1° / 5° increments) Minimum measurable pupil diameter ø2 mm Auto keratometer Measurement range Curvature radius 5.00 to 13.00 mm (0.01 mm increments) Refractive power 25.96 to 67.50 D (0.12 / 0.25 D increments) Cylindrical power 0 to 12.00 D (0.12 / 0.25 D increments) Axis 0 to 180º (1° / 5° increments) Sagittal measurement 25º each from the center (superior side, inferior side, temporal side, nasal side) Pupil size measurement range 1.0 to 10.0 mm (0.1 mm increments) Fixation Target Scenery Display 3.5-inch color LCD Interface USB: 1 port Wireless LAN (WLAN): 1ch (Wireless LAN (WLAN)-equipped model only) Power Specification Battery pack Lithium-ion battery (7.2 V 1800 mAh) Station feed DC 9 V 2 A (maximum) Dimensions / Mass 206 (W) × 181 (D) × 224 (H) mm (including occluders) / 998 g (including battery pack) 8.1 (W) x 7.1 (D) x 8.8 (H)" (including occluders) / 2.2 lbs. (including battery pack) Station Printer Thermal line printer with easy loading and auto cutter (printer-equipped model only) Interface USB: 1 port, LAN: 1 port, RS-232C: 1 port (printer-equipped model only) Battery charging Battery pack Lithium-ion battery (7.2 V 1800 mAh) Charging time When inserted in the main body: Approx. 180 min. (when the main body is placed on the station) When inserted in the battery slot: Approx. 140 min. Power supply AC 100 to 240 V, 50 / 60 Hz Power consumption 60 VA Dimensions / Mass 224 (W) x 283 (D) x 147 (H) mm / 2.7 kg (printer-equipped model), 2.5 kg (model without printer) 8.8 (W) x 11.1 (D) x 5.8 (H)" / 5.9 lbs. (printer-equipped model), 5.5 lbs. (model without printer) Standard accessories Occluder (2 units), Neck strap, Printer paper (3 rolls / printer-equipped model only), Power cord, Connection cable, Battery pack, Dust cover, Spherical model eye, Contact lens holder Optional accessories Carrying case, Carrying case with portable stand, Barcode scanner, Magnetic card reader, EyeCa-RW2, Eye Care card, Communication cable, Battery pack, USB flash drive
