CSL-2U Examination Slit Lamp
Details
Combine superior optics and traditional design with the The Briot CSL-2U Series. Its classical styling and outstanding Galilean optics are a good fit for any office. Complete with a three-step drum magnification system and moisture and mildew proof lenses. Features Include: Galilean Z Style 12.5x eyepiece magnification 10x,16x, 25x objective magnification Three-step revolving drum magnification Slit width: 0-14mm Slit length: 1-14mm Halogen or LED Illumination Variable intensity illumination mode Digital imaging available
Tech Specs
CSL-2U Technical Specifications Magnification Field of View Diameter 10x =22mm 16x =13.5mm 25x =22mm PD Adjustment 55-78mm Diopter Adjustment +/-6D Slit Angle 0-180° Slit Inclination 5°, 10°, 15°, 20° Aperture Diameter 14mm, 8mm, 3.5mm, 0.5mm Chin Rest Range 80mm Vertically Fixation Target Red LED Illumination 6v 20W Halogen Power 110/220V 50/60Hz 30VA Base Movement F/B= 90mm, L/R =100 Fine= 15mm, Vertical= 30mm Ship Weight 48.5lbs
