Kowa American Corporation
SL-17 Portable Slit Lamp

SL-17 Portable Slit Lamp

Brand:   Kowa SL-17
Condition:   New
The SL-17 weighs less than 800g and provides easy and versatile operation with a choice of 10x and 16x magnifications, 3 slit widths* (0.1mm, 0.2mm, 0.8mm) plus spot illumination and a cobalt blue filter using a high illumination LED as the light source.
Quantity:
Have a question? Feel free to Ask a question
Please Sign In To Inquire Price
If you just logged in, please refresh the page

Details

Kowa's Portable Slit Lamp is now LED light-based! SL 17 The SL-17 weighs less than 800g and provides easy and versatile operation with a choice of 10x and 16x magnifications, 3 slit widths* (0.1mm, 0.2mm, 0.8mm) plus spot illumination and a cobalt blue filter using a high illumination LED as the light source. The cobalt blue filter is useful for foreign body and contact lens applications. The SL-17 has a rheostat controlled light source from 0 to 20,000 Lux. The LED light source provides a much whiter light than ordinary halogen light sources found on competitive instruments. The SL-17 is compact and portable making it the ideal instrument for domiciliary environments, mobile evaluations, pediatrics, and patients not able to be imaged by a traditional slit lamp. The SL-17 is especially useful in emergency rooms where patient mobility is a challenge, or when switching between consultancy rooms is necessary. Offering cordless operation, the SL-17 is powered by (4) AAA rechargeable or dry cell batteries to provide long lasting, continuous operation of the extra-bright LED lamp. The slit lamp supports digital or video cameras via the optional c-mount camera adapter for instant imaging and documentation. Features and Benefits 20,000 Lux White LED Light Source Illumination is thumb wheel controlled and illuminated for easy viewing in a darkened room. Powered by AAA Batteries The Kowa SL-17 uses the following commercially available batteries: AAA rechargeable batteries AAA dry cell batteries * Excludes lithium-ion and lithium batteries Anti-Tip Design New circular base increases slit lamp stability providing a safer place to store the instrument Available in 4 Colors

Tech Specs

Specs Working Distance Approximately 80mm (16x) and Approximately 100mm (10x) Light Source White LED Type Binocular: Direct Image Type, Erected Real Image Angle of Convergence 13° Actual Field of View ⌀10mm(16x) ⌀15mm(10x) Magnification Change Built in Both Oculars Ocular Diopter -8D to +5D Slit Selection Turret Slit Length Fixed, 12mm Slit Width 0.1mm, 0.2mm, 0.8mm Light Intensity Adjustable Continuously Slit Projection Angle Horizontal ±60° Filter Built-in Cobalt Blue Filter Duration of Illumination Approximately 140 Minutes Electric Rating 8.4V d.c. (Special Purpose Battery), 15 W Power Unit Type (4) AAA Rechargeable or Dry Cell Batteries Power Unit Output Terminal For Charging Both Built-in and Extra Battery Power Supply Input: DC4.8 to 6.4V Power Consumption: 3.6 to 4.5VA Slit Lamp Dimensions 220(W) x 95(D) x 220(H) mm Slit Lamp Weight 745g (Batteries Not Included) Magnification 10x/16x Chin Rest Adjustment Range Movable Object Lens for 2 Magnifications: 50mm to 72mm
