HPE-810
Details
Auto / Manual 3D Simulation 3D simulation supports easier bevel / groove positioning and auto/manual positioning function will satisfy you on position of bevel / groove. Powerful Drill High power motor makes HPE-810 more powerful and leads to 40% reduction in processing time from previous model (HPE-7000). Design Your Imagination - Scan & Cut (Optional) As designs of glasses are diversifying, Scan & Cut function supports processing all designs without any restrictions. Scan your design and fit it in your frame with HPE-810.
Tech Specs
Specification Lens Material Plastic, Polycarbonate, High Index Plastic, Glass, Trivex Wheel Diameter 150mm, RPG Type Edging Mode Beveling (Normal / Auto / Manual Mode, Mini Bevel Option) Grooving (Normal / Auto / Manual Mode, Partial / Hybrid / Dual Grooving Option) Flat Edging Safety Beveling Polishing Functions Job Manager, Digital Pattern, Hole Editor, Retouch, Bevel / Groove Simulation, Shape Mirroring, Easy Click, Concave Shape, Scan & Cut (Optional) Utilities LCD Tilting Automatic Edging Room Door Edging Room illumination Simultaneous Bilateral feeling SD Card Storage (Memory Included) Barcode Reader (Optional) Vacuum Interface (Optional) HW Platform GUI (1GHz), Motor (120MHz) Display 9.7 inch Color TFT LCD(1024x768) with Touch Screen Edging Size Max : 90mm Min : Flat Edging : 18.5mm (without safety bevel) / 23.0mm (with safety bevel) Bevel Edging : 20mm (without safety bevel) / 24.7mm (with safety bevel) Drilling Hole Type : Hole, Slot, Notch Hole Size : Ø1.00~5.00mm Hole Depth : Max 6.0mm Range of Hole Drilling : Ø32.0~75.0mm from lens rotation axis, Slot Width : 1.0~5.0mm Slot Length : Max 20.0mm, Tilting Mode : Automatic, Manual (0~30°) Dimensions 540(W) x 462(D) x 597(H) Weight 55kg Power Supply AC 100~120V / AC 200~230V 50/60Hz Power Consumption 1200W(110V), 1500W(220V) Designs and details can be changed without prior notice for the purposes of improvement.
